PLATEC HA – 780 is an acid chelate cobalt system and organic brightener system High speed gold plating process, which suitable for connectors、terminals、changers plating、PCB gold finger and whole board gold plating.。The operate high current density range is also wild, good plating efficiency and another can lower the gold content of very uniform deposits gold thickness.the gold layer is meticulous and the lower porosity,accord with high corrosion resistance requirements.

1.lower running cost－
A. A.Lower the gold content operation
B. High stain resistance and long operating life
C. Formula is stable, Without aging phenomenon
D. Do not damage the anode ,Plating efficiency is stable

2. Operation is easy－Operating current density is broad， Brightness operating area don't suffer gold content change influence

3. Maintenance is easy－The efficiency is stable

4. Excellent uniform plating layer－The solution contain two kinds of organic brightener
Iimpel the cathode efficiency of The high current density area to reduce
The gold layer of high and low current density area is very uniform

5. High current efficiency－It can relieve the soldermask peeling

6. Excellent stain resistance of ability－Reference the sheet of impurity influence

7. Plating layer physical property is Excellent－The plating layer is meticulous, lower porosity and high corrosion resistance, Never color change, oxidation etc. failure Reference the plating layer physical property
